DOLD DDN45E Regler D-70736

DDN45E-Z-2P/3P

Nominal value / actual value display in operating mode, alternating parameter value / parameter display in input mode.

Jump to input level and operating level, confirmation key, keying through the parameters on one level.

Increasing code value, parameter value in input mode, switching key controller / manual actuator in operating mode.

Reducing code value, parameter value g Switching nominal value display / actual value display,

LED is lit during actual value display h LED is lit if output K 1 is active, LED flashes if output K 1 is locked

 LED is lit if output K 2 is active, LED flashes if output K 2 is locked

 LED is lit if logic input is active
