Brand: SQUARD D
MPN: JJL36250LCCA

SQUARD D
JJ 250
JJL36250LCCA
H- AND J-FRAME CIRCUIT BREAKERS
250A

H-FRAME AND J-FRAME MOLDED CASE CIRCUIT BREAKERS ARE DESIGNED TO PROTECT ELECTRICAL SYSTEMS FROM DAMAGE CAUSED BY OVERLOADS AND SHORT CIRCUITS. ALL CIRCUIT BREAKERS ARE DESIGNED TO OPEN AND CLOSE A CIRCUIT BY NONAUTOMATIC MEANS AND TO OPEN THE CIRCUIT AUTOMATICALLY ON A PREDETERMINED OVERCURRENT.

THE H-FRAME AND J-FRAME CIRCUIT BREAKER HANDLE CAN ASSUME ANY OF THREE POSITIONS, ON, TRIPPED OR OFF AS SHOWN. THE CENTER TRIPPED POSITION PROVIDES POSITIVE VISUAL INDICATION THAT THE CIRCUIT BREAKER HAS TRIPPED.

THE H-FRAME AND J-FRAME CIRCUIT BREAKERS ARE EQUIPPED WITH A THERMAL-MAGNETIC TRIP SYSTEM DESIGNED TO OPEN AUTOMATICALLY UNDER OVERLOAD OR SHORT CIRCUIT. H-FRAME AND J-FRAME CIRCUIT BREAKERS CONTAIN INDIVIDUAL THERMAL (OVERLOAD) AND MAGNETIC (SHORT CIRCUIT) SENSING ELEMENTS IN EACH POLE.
