Brand: BEKA
MPN: BA327C
Type: DIGIT INDICATOR

The BA327C is an intrinsically safe 41/2 digit panel mounting indicator which displays the current flowing in a 4/20mA loop in meaningful engineering units. The instrument is loop powered, but only introduces a 1V drop allowing it to be installed in series with almost any 4/20mA loop. Main application of the BA327C is to display a measured variable or control signal in a hazardous process area. The zero and span of the display are independently adjustable so that the indicator can easily be calibrated on-site to display any linear or square law signal represented by a 4/20mA current, such as temperature, flow or pressure. An optional 16 point linearizer enables the BA327C to display non linear variables in linear engineering units, and two optional alarms can control hazardous or safe area loads.
